EXTENDO Products

  • Extendo 944X - 1

    EXTENDO 944X

    EXTENDO 944X Offering several next gen optimizations, the Extendo 944X telehandler is powered by a standard 74-horsepower Deutz Tier 4 diesel engine and tried-and-true Pettibone hydraulics. This 9k telehandler features clear visibility, rough terrain...

  • Extendo 1044X -1

    EXTENDO 1044X

    EXTENDO 1044X Providing an impressive maximum load capacity of 10,000 pounds without the need for outriggers, the Extendo 1044X telehandler offers exceptional jobsite efficiency. REQUEST A QUOTE PRODUCT QUICK SPECS Maximum load capacity of 10,000...

  • Extendo 1046X - 1

    EXTENDO 1046X

    EXTENDO 1046X The Extendo 1046X is a heavy-duty 10,000-pound lift capacity machine that delivers up to 46 feet, 5 inches of lift height. This tough and efficient telehandler is equipped with a 74-horsepower Deutz Tier 4 diesel engine for maximum jobsite...

  • Extendo 1056X - 1

    EXTENDO 1056X

    EXTENDO 1056X The powerful Extendo 1056X telehandler delivers 10,000 pounds max load capacity with a lift height of up to 56 feet, 6 inches. This versatile, heavy-duty telescopic handler easily navigates rough terrain with exceptional maneuverability...

  • Extendo 1246X - 1

    EXTENDO 1246X

    EXTENDO 1246X The Extendo 1246X is a true material handling workhorse, delivering impressive load capacity, superior longevity, and controllability on a wide array of applications. This 12k telehandler can easily and efficiently place materials on...

  • Extendo 1256X - 1

    EXTENDO 1256X

    EXTENDO 1256X The Extendo 1256X telehandler takes rugged Pettibone performance to another level. Offering 12,000 pounds of load capacity with its 4-section boom, the 1256X is the ultimate machine for tough jobs. REQUEST A QUOTE PRODUCT QUICK...

  • Extendo 1536X - 1

    EXTENDO 1536X

    EXTENDO 1536X The Extendo 1536X telescopic handler delivers a maximum load capacity of 16,000 pounds, making it the ideal machine for heavy-duty material handling in pipe yards and highway construction jobs. Its excessive reach of 25 feet and maximum...

  • Extendo 1544X - 1

    EXTENDO 1544X

    EXTENDO 1544X The 15,000-pound-capacity Extendo 1544X offers up to 44 feet of lift height for enhanced lifting capabilities in highway construction, pipe yard handling, and building sites. This optimal material handling solution delivers unmatched power...

  • Interchangeable ad or promotion

Line Side Right

WHY CHOOSE An Extendo?

Generally, telescopic handlers are assumed to look and operate the same way - reaching outward and upward to lift and place loads into positions not possible with a straight mast forklift or other material handling equipment.

Pettibone Extendo, in contrast to competitive telehandlers, demonstrates superior engineering and features that massively improve safety and productivity. The Pettibone commitment to service, durability, and performance is clearly built into the design and functionality of these telescopic handlers.

Boom Design
Boom Design Image

Boom Design

For safely lifting thousands of pounds, the Extendo telehandlers offer maximum lift heights of up to 56 feet, 6 inches and forward reaches of up to 42 feet. The X-Series features formed boom plates for greater strength and reduced weight, minimizing deflection for better load control.

With nearly double the boom overlap of previous models, the Extendo provides smoother operation and extends service life. The bottom-mounted external extend cylinder reduces the load on the wear pads by up to 50%, which simplifies maintenance jobs, while heavy-duty extension chains ensure stable and long-lasting boom function.

Performance
Performance Design Image

Performance

Pettibone Extendo telehandlers are renowned for their revolutionary hydraulic circuit that delivers efficient performance, exceptional controllability, and fast cycle speeds with smooth, intuitive load handling. A single joystick controls all boom functions, and cylinder cushioning prevents wear from hard stops and load spills.

To enhance stability, the Extendo features a sway cylinder with 24 degrees of combined frame leveling — 12 degrees right and left of center — 20% more than typical telehandlers. Automatic fork leveling without slave cylinders performs well even in cold weather. A standard quick attach system turns the Extendo into an all-in-one telescopic handler, capable of operating with forks, buckets, balers, truss booms and side-tilt carriages.

Visibility
Visibility Image

Visibility

The Extendo’s chassis and boom structures are designed to improve operator visibility in all directions. The telehandler uses a single lift cylinder to improve sight lines to the rear. The side-mounted engine is positioned to allow an excellent curbside view. Models equipped with outriggers are designed to give operators good visibility to the fork tips. For even more enhanced visibility, a rear-view camera system is optional.

Another sightline hazard most telehandlers have is an extra set of slave cylinders near the pin where the boom is hinged, resulting in an additional obstacle to rear visibility. The Extendo’s design doesn’t require slave cylinders, eliminating this sightline hazard and improving overall rear visibility.

Reliability
Reliability Image

Reliability

The Extendo telehandlers are built ruggedly for easy maintenance and durable components. Built for longevity for the long haul, the Extendo operates using an easily accessible side pod mounted Cummins Tier 4 Final diesel engine, Dana high steer axles, and a Dana Powershift transmission, which are all designed for reliability and durability.

The hydraulic and fuel tanks are made of heavy-duty steel, not puncture-prone plastic, with a lockable fuel-fill in a clean, accessible location. Users can easily reach all filters and fluid level indicators, and the boom’s interior is also accessible for maintenance. Additionally, non-tensioned boom hoses also further extend service life.

Line Side Right
Video Banner 1544X Walk Around
Video Banner X

Operate today. Pay Tomorrow.

Learn about our dealer and owner financing programs with competitive interest and payment terms.

Learn More

Find a Local Dealer

Discover the closest dealer near you for the Pettibone machinery your job requires to accomplish successful projects.

Learn More

Support

Check out our Parts & Service team who’s ready to keep your machines up and running for the long haul.

Learn More

The new box construction of the Extendo 944X boom was noticeably more stable, especially under load and at full extension. The machine delivered plenty of power. What’s nice about the new machine is they’re using almost the same control system. It was very easy for the guys to transition from the older telehandler to the new model. Positioning the machine was very easy with how smooth the controls are.

Steve Peters President | Peters Building Contractors
!
